Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Desktop |
CPU | |
| Processor Installed | Intel Xeon E3-1515M, Intel i3-6100E |
Chipset | |
| Chipset | Intel CM236 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Maximum Memory | 32 GB |
Ethernet | |
| Controller Type | Intel i219-V 10/100/1000 Mbps |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 1 |
| RS-232 | 1 |
| USB Total | 4 |
| USB v3.x | 4 |
Drive interfaces | |
| MicroSD | 1 |
Extension Slots | |
| M.2 | 2 |
Connectors | |
| Connectors | 2xHDMI, 2xDisplayPort |
System Power Input | |
| Input Voltage DC | 12...19 V |
Dimensions and weight | |
| Width | 30 mm |
| Height | 180 mm |
| Depth | 119 mm |
Operating Conditions | |
| Operating Temperature | 0...45 °C |
