Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Built-in |
CPU | |
| СPU Generation/Family | Kaby Lake |
| Socket | LGA1151 |
| CPU Support Type | Celeron, Core i3, Core i5, Core i7 |
Chipset | |
| Chipset | Intel H310 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| ECC | No |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Controller Type | Intel i219-LM |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 1 |
| RS-232 | 1 |
| USB Total | 4 |
| USB 2.0 | 2 |
| USB v3.x | 2 |
Extension Slots | |
| Total | 2 |
| M.2 | 2 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | DB9, HDMI, RJ45 Ethernet, 4xUSB |
System Power Input | |
| Input Voltage DC | 12...12 V |
Software | |
| Operating System Compatibility | Linux OS, Windows 10 |
Dimensions and weight | |
| Width | 200 mm |
| Height | 30 mm |
| Depth | 119 mm |
Operating Conditions | |
| Operating Temperature | 0...45 °C |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
