Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Panel, Wall VESA 100 |
| Protection Level of Front Side (Panel) | IP65 |
| Type | Fan |
Display | |
| Display Type | LCD TFT |
| Diagonal | 15 " |
| Maximum resolution | 1024x768 Dots |
| Brightness | 300 Cd/m2 |
Touch Screen | |
| Touch Screen Type | Resistive |
CPU | |
| СPU Generation/Family | Alder Lake |
| Socket | LGA1700 |
| CPU Support Type | Pentium, Core i3, Core i5, Core i7 |
Chipset | |
| Chipset | Intel H610 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Maximum Memory | 64 GB |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Controller Type | Intel i225V, Intel i219-V 10/100/1000 Mbps |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 1 |
| 2,5 Gbit/s | 1 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-232/422 | 1 |
| USB Total | 6 |
| USB 2.0 | 4 |
| USB v3.x | 2 |
Drive interfaces | |
| SATA 3 | 1 |
Storage Cage | |
| Number Of Cage External | 1 |
| 2.5" Cage Intenal | 1 |
Extension Slots | |
| Total | 1 |
| PCI Express x16 | 1 |
LED / Controls | |
| LED | Power LED |
Connectors | |
| Connectors | DB15 VGA, HDMI, Display Port, 6xUSB, 2xRJ45 Ethernet, 2xDB9, Mic In, Line Out, AC Input |
System Power Input | |
| Input Voltage AC | 100...240 V |
| Power Consumption | 120 W |
Power Supply | |
| Type of Power Supply | Industrial, Internal |
| Output Power | 250 W |
Software | |
| Operating System Compatibility | Windows 10, Windows 11 |
Dimensions and weight | |
| Width | 378.3 mm |
| Height | 310.3 mm |
| Depth | 88.8 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
| Humidity | 10-90% |
Standards and Certifications | |
| Certifications | CE, IEC 61000-6-2, IEC 61000-6-4, FCC Class A |
