System Architecture | |
| Form Factor | COM Express Mini |
Construction | |
| Type | Fanless |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | LVDS, DisplayPort |
Ethernet | |
| Controller Type | Intel 82583V 10/100/1000 Mbps |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-232/422/485 | 1 |
| USB Total | 6 |
| USB 2.0 | 4 |
| USB v3.x | 2 |
| LPT | LPT |
Digital Input-Output | |
| Channels of DIO | 8 |
Audio | |
| Audio Controller | Realtek ALC662 |
Drive interfaces | |
| SATA 2 | 1 |
| CFast Slots | 1 |
Extension Slots | |
| Mini-PCIe/Mini Card | 1 |
Connectors | |
| Connectors | DB9, 2xRJ45 Ethernet, 2xUSB, Audio (in/out/Mic), DC Input, Display Port |
Dimensions and weight | |
| Width | 125 mm |
| Length | 95 mm |
Operating Conditions | |
| Operating Temperature | -40...85 °C |
| Humidity | 10-95% |
