System Architecture | |
| Form Factor | Full Size PICMG 1.3 |
CPU | |
| СPU Generation/Family | Comet Lake |
| CPU Support Type | Core i3, Core i5, Core i7, Pentium, Core i9, Xeon |
| Socket | LGA1200 |
Chipset | |
| Chipset | Intel W480E |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xDIMM |
| ECC | Yes |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Controller Type | Intel i210-AT, Intel i219-LM |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 2 |
| USB Total | 8 |
| USB 2.0 | 6 |
| USB v3.x | 2 |
Drive interfaces | |
| RAID Levels | 1, 5, 10 |
Extension Slots | |
| M.2 | 1 |
Connectors | |
| Internal Ports | 2xCOM, 4-pin (12V DC CPU), USB 3.0, 6xSATA 3, Display port |
| Connectors | DB15 VGA, 2xRJ45 Ethernet, 3xUSB |
Dimensions and weight | |
| Width | 338 mm |
| Length | 122 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
