Specification
System Architecture | |
| System Bus | Universal PCI |
Digital Input | |
| Total channels of digital input | 6 |
| Isolation of Digital Input | 2500 V |
| Type | Dry contact, Wet contact |
| Sink/Source | Sink |
| Level of Logic "0" | 21~24 V |
| Level of Logic "1" | 0~16 V |
| Max frequency | 1 kHz |
| Signal Type | A/B, Up/Down |
Digital Output | |
| Total channels of digital output | 8 |
| Type | Open collector |
| Signal Type | CW/CCW, Pulse/Dir |
| Sink/Source | Sink |
| Output voltage | 5~40 V |
| Max. load current | 200 mA |
| Channels | 2 |
| Output frequency range | 0~4 MHz |
Connectors | |
| Connectors | 50-pin SCSI II Female |
Software | |
| Operating System Compatibility | Windows XP, Windows 7 |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
Standards and Certifications | |
| Certifications | CE/FCC |
