System Architecture | |
| System Bus | Universal PCI |
Digital Input | |
| Total channels of digital input | 32 |
| Isolation of Digital Input | 2500 V |
| Type | Wet contact |
| Sink/Source | Sink |
| Level of Logic "0" | 0~4 V |
| Level of Logic "1" | 10~30 V |
| Max frequency | 10 kHz |
| Signal Type | A/B |
Digital Output | |
| Total channels of digital output | 32 |
| Type | Open collector |
| Signal Type | CW/CCW, Pulse/Dir |
| Sink/Source | Sink |
| Output voltage | 10~30 V |
| Max. load current | 60 mA |
| Channels | 8 |
| Output frequency range | 0~5 MHz |
Connectors | |
| Connectors | 2x100-pin mini-SCSI Female |
Software | |
| Operating System Compatibility | Windows XP, Windows 7 |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
Standards and Certifications | |
| Certifications | CE/FCC |
