Specification
System Architecture | |
| System Bus | Universal PCI |
Analog Input | |
| Total channels of analog input | 16 |
| Single-Ended channels | 16 |
| Differential channels | 8 |
| Number of Bits | 12 Bit |
| Sampling rate | 100 Hz |
| Voltage range | +/-1.25 V, +/-2.5 V, +/-5 V, +/-10 V, 0...2.5 V, 0...5 V, 0...10 V |
Digital Input | |
| Total channels of digital input | 16 |
| Type | Wet contact |
| Level of Logic "0" | 0~0.8 V |
| Level of Logic "1" | 2~5 V |
| Number of channels | 1 |
| Counter capacity | 16 Bit |
| Max frequency | 1 kHz |
Digital Output | |
| Total channels of digital output | 16 |
| Type | Open collector |
| Output voltage | 0~5 V |
Connectors | |
| Connectors | 68-pin SCSI-II |
Software | |
| Operating System Compatibility | Windows XP, Windows 7, Windows 8 |
| Development Software | Visual Studio .NET, LabVIEW |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
Standards and Certifications | |
| Certifications | CE/FCC |
