System Architecture | |
| System Bus | PCI |
Analog Input | |
| Total channels of analog input | 32 |
| Single-Ended channels | 32 |
| Differential channels | 16 |
| Number of Bits | 16 Bit |
| Sampling rate | 250 Hz |
| Voltage range | +/-1 V, +/-10 V |
Digital Input | |
| Total channels of digital input | 16 |
| Isolation of Digital Input | 2500 V |
| Type | Wet contact |
| Sink/Source | Sink |
| Level of Logic "0" | 0~1.5 V |
| Level of Logic "1" | 5~24 V |
| Number of channels | 1 |
| Counter capacity | 16 Bit |
| Max frequency | 2 kHz |
Digital Output | |
| Total channels of digital output | 16 |
| Type | Open collector |
| Sink/Source | Sink |
| Output voltage | 5~35 V |
| Max. load current | 350 mA |
Connectors | |
| Internal Ports | 2x20-pin box header |
| Connectors | DB37 Female |
Software | |
| Operating System Compatibility | Windows XP, Windows 7, Linux OS |
| Development Software | Visual Studio .NET, MATLAB, LabVIEW, AD-Logger, DAQBench |
Operating Conditions | |
| Operating Temperature | 0...55 °C |
