System Architecture | |
| System Bus | Universal PCI |
Digital Input-Output | |
| Channels of DIO | 32 |
Digital Input | |
| Total channels of digital input | 32 |
| Type | Wet contact |
| Sink/Source | Sink, Source |
| Level of Logic "0" | 0~0.8 V |
| Level of Logic "1" | 2~5 V |
| Number of channels | 16 |
| Counter capacity | 32 Bit |
| Max frequency | 250 kHz |
| Signal Type | Frequency, Up |
Digital Output | |
| Total channels of digital output | 32 |
| Type | Open collector |
| Sink/Source | Sink, Source |
| Output voltage | 5~5 V |
| Max. load current | 2.4 mA |
Connectors | |
| Internal Ports | 2x20-pin box header |
| Connectors | DB37 Female |
Software | |
| Operating System Compatibility | Windows XP, Windows 7, Windows 8 |
| Development Software | Visual Studio .NET, MATLAB, LabVIEW |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
