Specification
System Architecture | |
| System Bus | PCI-Express x1 |
Digital Input-Output | |
| Channels of DIO | 96 |
Digital Input | |
| Total channels of digital input | 96 |
| Level of Logic "0" | 0~0.8 V |
| Level of Logic "1" | 2~5.25 V |
| Number of channels | 1 |
| Counter capacity | 16 Bit |
Digital Output | |
| Total channels of digital output | 96 |
| Output voltage | 0.5~2.4 V |
| Max. load current | 24 mA |
Connectors | |
| Internal Ports | 4x50-pin box header |
Software | |
| Operating System Compatibility | Windows Server 2003, Windows XP, Linux OS, Windows 2000, Windows Vista |
| Development Software | VC, VB, Delphi, BCB, AD-Logger, DAQBench |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
