Specification
System Architecture | |
| System Bus | PCI-Express x1 |
Analog Input | |
| Total channels of analog input | 4 |
| Differential channels | 4 |
| Number of Bits | 24 Bit |
| Sampling rate | 15000 Hz |
| Voltage range | +/-1.25 V, +/-2.5 V, +/-5 V, +/-10 V |
Analog Output | |
| Channels of analog input | 2 |
| Voltage range | +/-5 V, +/-10 V |
Digital Input | |
| Total channels of digital input | 16 |
| Isolation of Digital Input | 2500 V |
| Type | Wet contact |
| Sink/Source | Sink, Source |
| Level of Logic "0" | 0~1 V |
| Level of Logic "1" | 5~24 V |
| Number of channels | 2 |
| Counter capacity | 32 Bit |
| Max frequency | 12 kHz |
| Signal Type | CW/CCW, Pulse/Dir, AB Phase |
Digital Output | |
| Total channels of digital output | 16 |
| Type | Open collector |
| Signal Type | CW/CCW, Pulse/Dir |
| Sink/Source | Sink |
| Output voltage | 0~30 V |
| Max. load current | 100 mA |
| Channels | 2 |
| Output frequency range | 0~4 MHz |
Connectors | |
| Connectors | 2x68-pin SCSI VHDCI |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
