System Architecture | |
| Form Factor | Full Size PICMG 1.3 |
CPU | |
| CPU Support Type | Celeron, Core i3, Core i5, Core i7, Pentium |
| Socket | LGA1150 |
Chipset | |
| Chipset | Intel Q87 |
Memory | |
| Form-factor | DDR3, DDR3L |
| Socket Type | 4xDIMM |
| Maximum Memory | 32 GB |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | VGA |
Ethernet | |
| Controller Type | Intel i217LM 10/100/1000 Mbps, Intel i210-AT |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 5 |
| RS-232 | 4 |
| RS-422/485 | 1 |
| USB Total | 8 |
| USB 2.0 | 4 |
| USB v3.x | 4 |
| LPT | LPT |
Drive interfaces | |
| RAID Levels | 1, 5, 10 |
| mSATA | 1 |
Extension Slots | |
| Total | 1 |
| Mini-PCIe/Mini Card | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | IRDA, 10-pin DIO, TPM, 4-pin SMBus, 4-pin I2C, 1x4-pin RS-422/485, 26-pin LPT, 4x10-pin RS-232, 4x4-pin USB 2.0, iDP, iRIS-2400, 6-pin KB/MS, 4-pin ATX, 6xSATA, 19-pin USB 3.0 |
| Connectors | DB15 VGA, 2xRJ45 Ethernet, 2xUSB |
Dimensions and weight | |
| Width | 126 mm |
| Length | 338 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
