System Architecture | |
| Form Factor | 3.5" |
Construction | |
| Type | Fanless |
CPU | |
| Processor Installed | DM&P Vortex86DX |
| Max CPU frequency | 0.8 GHz |
Memory | |
| Form-factor | DDR2 |
| Default on Board Memory | 0.5 GB |
| Maximum Memory | 0.5 GB |
Graphic | |
| Graphic Controller | SMI 712 |
| Interfaces | LVDS, VGA |
Ethernet | |
| Total Ethernet | 2 |
| 10/100 Mbit/s | 2 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 3 |
| RS-232/422/485 | 1 |
| USB Total | 4 |
| USB 2.0 | 4 |
| LPT | LPT |
Drive interfaces | |
| CompactFlash Slots | 1 |
Extension Slots | |
| Total | 1 |
| PC/104 | 1 |
Additional Functions | |
| Watchdog timer type | Hardware |
Connectors | |
| Connectors | DB9, DB15 VGA, LVDS, PS/2 Keyboard/Mouse, RJ45 |
Software | |
| Operating System Compatibility | Windows CE 6.0, Windows XP Embedded, Linux OS, Vxworks, QNX |
Dimensions and weight | |
| Width | 146 mm |
| Length | 102 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
