System Architecture | |
| Form Factor | 3.5" |
Construction | |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Atom N455 |
| Max CPU frequency | 1.66 GHz |
Chipset | |
| Chipset | Intel ICH8M |
Memory | |
| Form-factor | DDR3 |
| Socket Type | 1xSODIMM |
| Default on Board Memory | 1 GB |
| Maximum Memory | 2 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | LVDS, VGA |
Ethernet | |
| Controller Type | Intel 82583V 10/100/1000 Mbps, Intel 82567V 10/100/1000 Mbps |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| RS-232 | 2 |
| RS-232/422/485 | 1 |
| USB Total | 6 |
| USB 2.0 | 6 |
| LPT | LPT |
Digital Input-Output | |
| Channels of DIO | 8 |
Audio | |
| Audio Controller | Realtek ALC892 |
Drive interfaces | |
| CompactFlash Slots | 1 |
Extension Slots | |
| Total | 1 |
| Mini-PCIe/Mini Card | 1 |
Additional Functions | |
| Watchdog timer type | Hardware |
Connectors | |
| Connectors | DB9, DB15 VGA, 2xRJ45 Ethernet, 2xUSB |
Software | |
| Operating System Compatibility | Windows CE 6.0, Windows XP Embedded, Windows Embedded Standard 7, QNX 6, Ubuntu 10.04, Windows CE 7.0, Vxworks |
Dimensions and weight | |
| Width | 146 mm |
| Length | 102 mm |
Operating Conditions | |
| Operating Temperature | -40...85 °C |
