System Architecture | |
| Form Factor | 3.5" |
Construction | |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Celeron N2930 |
| Max CPU frequency | 2.16 GHz |
Chipset | |
| Chipset | Intel Bay Trail-I SoC |
Memory | |
| Form-factor | DDR3L |
| Default on Board Memory | 4 GB |
| Maximum Memory | 4 GB |
Graphic | |
| Graphic Controller | Intel Gen7 graphic engine |
| Interfaces | LVDS, VGA |
Ethernet | |
| Controller Type | Realtek RTL8111E PCIe GbE |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 3 |
| RS-232/422/485 | 1 |
| USB Total | 6 |
| USB 2.0 | 5 |
| USB v3.x | 1 |
Digital Input-Output | |
| Channels of DIO | 8 |
Audio | |
| Audio Controller | Realtek ALC888 HD |
Drive interfaces | |
| mSATA | 1 |
Extension Slots | |
| Total | 2 |
| Mini-PCIe/Mini Card | 1 |
| PCI-104 | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | DB9, DB15 VGA, 2xRJ45 Ethernet, 2xUSB |
Software | |
| Operating System Compatibility | Android, Windows Embedded Compact 7, Windows Embedded Standard 7, Windows Embedded Standard 8, Linux OS, Vxworks |
Dimensions and weight | |
| Width | 146 mm |
| Length | 102 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
