System Architecture | |
| Form Factor | 3.5" |
Construction | |
| Type | Fanless |
CPU | |
| Processor Installed | AMD LX800 |
| Socket | CPU onboard |
| Max CPU frequency | 0.5 GHz |
Chipset | |
| Chipset | AMD LX800 + AMD CS5536 |
Memory | |
| Form-factor | DDR |
| Socket Type | 1xSODIMM |
| ECC | No |
| Maximum Memory | 1 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Geode LX800 |
| Interfaces | LVDS, VGA |
Ethernet | |
| Controller Type | Realtek RTL8139 10 Base T/100 Base TX |
| Total Ethernet | 2 |
| 10/100 Mbit/s | 2 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 3 |
| RS-232/422/485 | 1 |
| USB Total | 4 |
| USB 2.0 | 4 |
| LPT | LPT |
Digital Input-Output | |
| Channels of DIO | 8 |
Audio | |
| Audio Controller | Realtek ALC203 |
Drive interfaces | |
| CompactFlash Slots | 1 |
Extension Slots | |
| Total | 1 |
| PC/104 | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | DB9, DB15 VGA, PS/2 Keyboard, RJ45 Ethernet |
Software | |
| Operating System Compatibility | Windows CE 6.0, Windows Embedded Standard 2009, Linux OS, Vxworks, QNX |
Dimensions and weight | |
| Width | 146 mm |
| Length | 102 mm |
Operating Conditions | |
| Operating Temperature | -20...80 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
