System Architecture | |
| Form Factor | 3.5" |
CPU | |
| Processor Installed | Intel Celeron N3350 |
| Max CPU frequency | 2.4 GHz |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 1xSODIMM |
| Maximum Memory | 8 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Controller Type | Intel i210 |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 6 |
| RS-232 | 4 |
| RS-232/422/485 | 2 |
| USB Total | 8 |
| USB 2.0 | 6 |
| USB v3.x | 2 |
| LPT | LPT |
Drive interfaces | |
| mSATA | 1 |
Extension Slots | |
| Total | 4 |
| M.2 | 1 |
| Mini-PCIe/Mini Card | 1 |
| PCI | 1 |
| PCI-104 | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | COM, SATA 3, USB 2.0, 4-pin (12V DC CPU), HDMI, USB 3.0, 16-pin VGA, 10-pin GbE, 40-pin eDP |
Software | |
| Operating System Compatibility | Windows IoT Enterprise 10, Windows 10 |
Dimensions and weight | |
| Width | 203 mm |
| Length | 146 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
