System Architecture | |
| Form Factor | COM Express Compact |
Construction | |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Pentium N4200 |
| Socket | CPU onboard |
| Max CPU frequency | 2.5 GHz |
Chipset | |
| Chipset | Intel Atom SoC |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 2xSODIMM |
| Maximum Memory | 16 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | DisplayPort, LVDS, VGA |
Ethernet | |
| Controller Type | Intel i219-LM |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| USB Total | 11 |
| USB 2.0 | 8 |
| USB v3.x | 3 |
Audio | |
| Audio Controller | Intel HD Audio |
Extension Slots | |
| PCI Express x1 | 4 |
Dimensions and weight | |
| Width | 95 mm |
| Length | 95 mm |
Operating Conditions | |
| Operating Temperature | -40...85 °C |
