System Architecture | |
| Form Factor | Full Size PICMG 1.3 |
CPU | |
| СPU Generation/Family | Skylake |
| Socket | LGA1151 |
Chipset | |
| Chipset | Intel Q170 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xDIMM |
| Maximum Memory | 32 GB |
Graphic | |
| Graphic Controller | Intel HD 530 graphics |
| Interfaces | VGA |
Ethernet | |
| Controller Type | Intel i211, Intel WGI219LM 10/100/1000 Mbps |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 3 |
| RS-232/422/485 | 1 |
| USB Total | 10 |
| USB 2.0 | 6 |
| USB v3.x | 4 |
| LPT | LPT |
Drive interfaces | |
| RAID Levels | 1, 5, 10 |
Extension Slots | |
| M.2 | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | DB15 VGA, 2xRJ45 Ethernet, 2xUSB |
Dimensions and weight | |
| Width | 126.4 mm |
| Length | 338.6 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
