Construction |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
Digital Input |
| Total channels of digital input | 12 |
| Type | Wet contact |
| Level of Logic "0" | 0~4 V |
| Level of Logic "1" | 10~50 V |
| Sink/Source | Sink, Source |
| Counter capacity | 32 Bit |
| Max frequency | 0.5 kHz |
| Counter | 500Hz, 32 bit |
Digital Output |
| Total channels of digital output | 6 |
| Type | Open collector |
| Sink/Source | Sink |
| Output voltage | 5~30 V |
| Max. load current | 100 mA |
Supported Protocols |
| Industrial Protocols | Modbus TCP server, Modbus UDP slave |
Connectors |
| Connectors | Screw Terminal |
Additional Functions |
| Watchdog timer type | Hardware, Software |
System Power Input |
| Input Voltage DC | 12...48 V |
| Power over Ethernet (PoE) | PoE |
Dimensions and weight |
| Width | 72 mm |
| Depth | 35 mm |
| Height | 123 mm |
Operating Conditions |
| Operating Temperature | -25...75 °C |
Standards and Certifications |
| EMS | IEC 61000-4-2, IEC 61000-4-4 |
