Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
Digital Input | |
| Total channels of digital input | 6 |
| Type | Wet contact |
| Level of Logic "0" | 0~4 V |
| Level of Logic "1" | 10~50 V |
| Sink/Source | Sink, Source |
| Isolation of Digital Input | 3750 V |
| Counter capacity | 32 Bit |
| Max frequency | 0.5 kHz |
| Counter | 500Hz, 32 bit |
Digital Output | |
| Total channels of digital output | 6 |
| Type | PhotoMos relay |
| Relay (Form A) | 6 |
| Contact rating of relay (Form A) | 1A@60V DC |
Supported Protocols | |
| Industrial Protocols | Modbus TCP server, Modbus UDP slave |
Additional Functions | |
| Watchdog timer type | Hardware, Software |
System Power Input | |
| Input Voltage DC | 12...48 V |
| Power over Ethernet (PoE) | PoE |
Dimensions and weight | |
| Width | 35 mm |
| Depth | 123 mm |
| Height | 75 mm |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
