Construction |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
Ethernet |
| 10/100 Mbit/s | 2 |
Supported Protocols |
| Industrial Protocols | Modbus TCP server, Modbus UDP slave |
Analog Input |
| Total channels of analog input | 7 |
| Number of Bits | 16 Bit |
| Sampling rate | 12 Hz |
| Differential channels | 7 |
| Thermal resistance | Pt100, Pt1000, Ni120, Cu100, Cu1000 |
Connectors |
| Connectors | Screw Terminal |
Additional Functions |
| Watchdog timer type | Hardware, Software |
System Power Input |
| Input Voltage DC | 12...48 V |
| Power over Ethernet (PoE) | PoE |
Dimensions and weight |
| Width | 76 mm |
| Depth | 38 mm |
| Height | 120 mm |
Operating Conditions |
| Operating Temperature | -25...75 °C |
Standards and Certifications |
| EMS | IEC 61000-4-2, IEC 61000-4-4, IEC 61000-4-5 |
