PET-7258M-16-UTA

Name: PET-7258M-16-UTA
Brand: ICP DAS
SKU: 09352500
Availability: InStock

ICP DAS

Ціна за запитом

Ethernet I/O Module with 2-port Ethernet Switch, with 16-channels AC/DC Digital Input, PoE, -40...+75C

Специфікація

Specification

Construction
Construction Chassis	Metal Chassis
Mounting Configuration	Wall, DIN-Rail mount
Digital Input
Total channels of digital input	16
Type	Wet contact
Level of Logic "0"	0~4 V
Level of Logic "1"	80~250 V
Sink/Source	Sink, Source
Counter capacity	32 Bit
Max frequency	0.1 kHz
Counter	100Hz, 32 bit
Supported Protocols
Industrial Protocols	Modbus TCP server, Modbus UDP slave
Additional Functions
Watchdog timer type	Hardware, Software
System Power Input
Input Voltage DC	12...48 V
Power over Ethernet (PoE)	PoE
Dimensions and weight
Width	38 mm
Depth	130 mm
Height	97 mm
Operating Conditions
Operating Temperature	-40...75 °C
Standards and Certifications
EMS	IEC 61000-4-2, IEC 61000-4-4
