Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall |
Analog Input | |
| Total channels of analog input | 8 |
| Number of Bits | 16 Bit |
| Voltage range | +/-5 V, +/-10 V |
| Sampling rate | 200000 Hz |
| Single-Ended channels | 8 |
Digital Input | |
| Total channels of digital input | 4 |
| Type | Wet contact |
| Level of Logic "0" | 0~1 V |
| Level of Logic "1" | 5~30 V |
| Sink/Source | Wet: Sink/Source |
Digital Output | |
| Total channels of digital output | 4 |
| Type | Open collector |
| Sink/Source | Sink |
| Output voltage | 5~30 V |
| Max. load current | 100 mA |
Supported Protocols | |
| Industrial Protocols | Modbus TCP server |
System Power Input | |
| Input Voltage DC | 12...48 V |
| Power over Ethernet (PoE) | PoE |
Dimensions and weight | |
| Width | 76 mm |
| Depth | 38 mm |
| Height | 120 mm |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
Standards and Certifications | |
| EMS | IEC 61000-4-2, IEC 61000-4-4 |
