Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall |
Analog Input |
| Total channels of analog input | 4 |
| Number of Bits | 24 Bit |
| Voltage range | +/-150 mV, +/-1.25 V, +/-2.5 V, +/-5 V, +/-10 V, +/- 20 mV, +/-625 mV |
| Sampling rate | 128000 Hz |
| Single-Ended channels | 4 |
Analog Output |
| Channels of analog input | 2 |
| DAC Bit Rate | 12 Bit |
| Voltage range | 0...5 V, 0...10 V, +/-5 V, +/-10 V |
Digital Input |
| Total channels of digital input | 3 |
| Type | Wet contact |
| Level of Logic "0" | 0~2 V |
| Level of Logic "1" | 5~30 V |
| Sink/Source | Wet: Sink/Source |
| Isolation of Digital Input | 2500 V |
| Number of channels | 1 |
| Signal Type | CW/CCW, Pulse/Dir, Quadrant |
| Counter capacity | 32 Bit |
| Max frequency | 6 kHz |
| Counter | 1 kHz |
Digital Output |
| Total channels of digital output | 4 |
| Type | Open collector |
| Sink/Source | Sink |
| Output voltage | 5~30 V |
| Max. load current | 100 mA |
Supported Protocols |
| Industrial Protocols | Modbus TCP server |
System Power Input |
| Input Voltage DC | 12...48 V |
| Power over Ethernet (PoE) | PoE |
Dimensions and weight |
| Width | 76 mm |
| Depth | 38 mm |
| Height | 120 mm |
Operating Conditions |
| Operating Temperature | -25...75 °C |
Standards and Certifications |
| EMS | IEC 61000-4-2, IEC 61000-4-4 |
