Specification
System Architecture | |
| System Bus | PCI-Express x1 |
Digital Input-Output | |
| Channels of DIO | 24 |
Digital Input | |
| Total channels of digital input | 24 |
| Level of Logic "0" | 0~0.8 V |
| Level of Logic "1" | 2~5 V |
Digital Output | |
| Total channels of digital output | 24 |
| Output voltage | 0~5 V |
| Max. load current | 64 mA |
Connectors | |
| Connectors | DB37 Female |
Software | |
| Operating System Compatibility | Linux kernel 2.6, Windows XP, Windows 7, Windows Vista |
| Development Software | VC, VB, Delphi, BCB, LabVIEW |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
