Specification
System Architecture | |
| System Bus | PCI-Express x1 |
Digital Input | |
| Total channels of digital input | 16 |
| Isolation of Digital Input | 2000 V |
| Level of Logic "0" | 0~1 V |
| Level of Logic "1" | 5~24 V |
Digital Output | |
| Total channels of digital output | 16 |
| Type | PhotoMos relay |
| Relay (Form A) | 16 |
| Contact rating of relay (Form A) | 0.13A@350V AC, 0.13A@350V DC |
Connectors | |
| Internal Ports | 40-pin box header |
| Connectors | DB37 Female |
Software | |
| Operating System Compatibility | Linux kernel 2.6, Windows XP, Windows 7, Windows Vista |
| Development Software | VC, VB, Delphi, BCB, LabVIEW |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
