Specification
System Architecture | |
| System Bus | PCI-Express x1 |
Digital Input | |
| Total channels of digital input | 8 |
| Isolation of Digital Input | 3750 V |
| Level of Logic "0" | 0~1 V |
| Level of Logic "1" | 5~24 V |
Digital Output | |
| Total channels of digital output | 8 |
| Type | Electromagnitic relay |
| Relay (Form A) | 4 |
| Contact rating of relay (Form A) | 05A@120V AC, 1A@24V DC |
| Relay (Form C) | 4 |
| Contact rating of relay (Form C) | 0.5A@120V AC |
Connectors | |
| Internal Ports | 40-pin box header |
| Connectors | DB37 Female |
Software | |
| Operating System Compatibility | Linux kernel 2.6, Windows XP, Windows 7, Windows Vista |
| Development Software | VC, VB, Delphi, BCB, LabVIEW |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
