Specification
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | DIN-Rail mount |
Ethernet | |
| 10/100 Mbit/s | 2 |
Supported Protocols | |
| Industrial Protocols | PROFINET slave |
Digital Input | |
| Total channels of digital input | 16 |
| Type | Dry contact |
| Sink/Source | Dry: Source |
Connectors | |
| Connectors | Screw Terminal |
System Power Input | |
| Input Voltage DC | 10...30 V |
Dimensions and weight | |
| Width | 33 mm |
| Depth | 107 mm |
| Height | 126 mm |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
