CPU | |
| СPU Generation/Family | Apollo Lake |
| Processor Installed | Intel Celeron J3455 |
| Max CPU frequency | 2.3 GHz |
Chipset | |
| Chipset | Intel Apollo Lake SoC |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 1xSODIMM |
| ECC | No |
| Maximum Memory | 8 GB |
| Assembly | Removable |
Graphic | |
| Interfaces | DisplayPort, LVDS |
Ethernet | |
| Controller Type | Intel i210-AT |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-232/422/485 | 1 |
| USB Total | 4 |
| USB 2.0 | 2 |
| USB v3.x | 2 |
Digital Input-Output | |
| Channels of DIO | 4 |
Drive interfaces | |
| M.2 | 1 |
Extension Slots | |
| Mini-PCIe/Mini Card | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 2xUSB, 2xRJ45 Ethernet, Display Port |
Software | |
| Operating System Compatibility | Windows 10 |
Dimensions and weight | |
| Width | 100 mm |
| Length | 72 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
| Humidity | 10-95% |
