System Architecture | |
| Form Factor | PICO-ITX |
Construction | |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Skylake |
| Processor Installed | Intel Core i3-7100U |
| Socket | CPU onboard |
| Max CPU frequency | 2.4 GHz |
| Number of CPU | 1 |
Chipset | |
| Chipset | Intel Skylake SoC |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 1xSODIMM |
| Maximum Memory | 16 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | LVDS, HDMI |
Ethernet | |
| Controller Type | Intel i219-LM |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| USB Total | 1 |
| USB 2.0 | 1 |
Drive interfaces | |
| mSATA | 1 |
Extension Slots | |
| Total | 2 |
| Mini-PCIe/Mini Card | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | HDMI, RJ45 Ethernet, DC Input |
Dimensions and weight | |
| Width | 100 mm |
| Length | 72 mm |
Operating Conditions | |
| Operating Temperature | -20...70 °C |
Standards and Certifications | |
| Certifications | CE |
