Construction | |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Whiskey Lake |
| Processor Installed | Intel Core i3-8145UE |
| Max CPU frequency | 3.9 GHz |
Chipset | |
| Chipset | Intel Whiskey lake SoC |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 1xSODIMM |
| Maximum Memory | 16 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | DisplayPort, LVDS, HDMI |
Ethernet | |
| Controller Type | Intel i211-AT 10/100/1000 Mbps, Intel i219-LM |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 4 |
| USB 2.0 | 2 |
| USB v3.x | 2 |
Digital Input-Output | |
| Channels of DIO | 4 |
Extension Slots | |
| M.2 | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | 2xCOM, SATA 3, 2xUSB 2.0, 10-pin DIO |
| Connectors | HDMI, RJ45, 2xUSB, Display Port |
Dimensions and weight | |
| Width | 100 mm |
| Length | 72 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
Standards and Certifications | |
| Certifications | CE |
