System Architecture | |
| Form Factor | PICO-ITX |
Construction | |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Bay Trail |
| Processor Installed | Intel Atom E3845 |
| Max CPU frequency | 1.91 GHz |
Chipset | |
| Chipset | Intel Bay Trail-I SoC |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 1xSODIMM |
| Maximum Memory | 8 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | LVDS, VGA |
Ethernet | |
| Controller Type | Intel i211-AT 10/100/1000 Mbps |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 4 |
| USB 2.0 | 4 |
Audio | |
| Audio Controller | Intel HD Audio |
Extension Slots | |
| Total | 2 |
| Mini-PCIe/Mini Card | 2 |
Additional Functions | |
| Watchdog timer type | Hardware |
Dimensions and weight | |
| Width | 100 mm |
| Length | 72 mm |
Operating Conditions | |
| Operating Temperature | -20...70 °C |
Standards and Certifications | |
| Certifications | CE |
