System Architecture |
| System Bus | Universal PCI |
Analog Input |
| Total channels of analog input | 16 |
| Single-Ended channels | 16 |
| Differential channels | 8 |
| Number of Bits | 12 Bit |
| Sampling rate | 45000 Hz |
| Voltage range | +/-5 V, +/-500 mV, +/-50 mV, +/-5 mV |
Analog Output |
| Channels of analog input | 1 |
| Voltage range | 0...5 V, 0...10 V |
Digital Input |
| Total channels of digital input | 16 |
| Level of Logic "0" | 0~0.8 V |
| Level of Logic "1" | 2~5 V |
| Number of channels | 3 |
| Counter capacity | 16 Bit |
| Max frequency | 10 kHz |
Digital Output |
| Total channels of digital output | 16 |
| Output voltage | 0~5 V |
| Max. load current | 2.4 mA |
Connectors |
| Internal Ports | 2x20-pin box header |
| Connectors | DB37 Female |
Software |
| Operating System Compatibility | Linux kernel 2.6, Windows XP, Windows 7, Windows 8, Windows Vista |
| Development Software | VC, VB, Delphi, BCB, MATLAB, LabVIEW |
Operating Conditions |
| Operating Temperature | 0...60 °C |
