System Architecture |
| System Bus | Universal PCI |
Analog Output |
| Channels of analog input | 4 |
| Current range | 0...20 mA, 4...20 mA |
| Voltage range | 0...5 V, 0...10 V, +/-5 V, +/-10 V |
Digital Input |
| Total channels of digital input | 16 |
| Level of Logic "0" | 0~0.8 V |
| Level of Logic "1" | 2~5 V |
| Number of channels | 3 |
| Counter capacity | 16 Bit |
| Max frequency | 4 kHz |
Digital Output |
| Total channels of digital output | 16 |
| Output voltage | 0~5 V |
| Max. load current | 2.4 mA |
Connectors |
| Internal Ports | 2x20-pin box header |
| Connectors | DB37 Female |
Cables |
| Included Cables | CA-3710 |
Software |
| Operating System Compatibility | Linux kernel 2.6, Windows XP, Windows 7, Windows 8, Windows Vista |
| Development Software | VC, VB, Delphi, BCB, Visual Studio .NET, LabVIEW |
Operating Conditions |
| Operating Temperature | 0...60 °C |
