Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall, Ceiling mounting |
| Protection Level of Chassis | IP20 |
Supported Protocols | |
| Industrial Protocols | Modbus TCP server, Modbus RTU slave, DCON slave |
Ethernet | |
| 10/100 Mbit/s | 1 |
System Power Input | |
| Power over Ethernet (PoE) | IEEE 802.3af |
| Input Voltage DC | 18...48 V |
Interfaces | |
| RS-485 | 1 |
Wi-Fi | |
| Wi-Fi Standard | 802.11b/g/n |
Sensors | |
| Measuring Range | -40...+120 °C |
| Resolution | 0.01 °C |
| Accuracy (+/-) | 0.5 °C |
| Measuring Range | 0…100% |
| Resolution | 0 % |
| Accuracy (+/-) | 0 % |
| Detection range | 4 m |
Dimensions and weight | |
| Width | 150 mm |
| Height | 53 mm |
Standards and Certifications | |
| EMS | IEC 61000-4-2, IEC 61000-4-4 |
