System Architecture |
| System Bus | Universal PCI |
Digital Input |
| Total channels of digital input | 32 |
| Isolation of Digital Input | 3750 V |
| Level of Logic "0" | 0~1 V |
| Level of Logic "1" | 9~24 V |
Digital Output |
| Total channels of digital output | 32 |
| Type | Open collector |
| Sink/Source | Source |
| Output voltage | 0~30 V |
| Max. load current | 100 mA |
Connectors |
| Internal Ports | 2x20-pin box header |
| Connectors | DB37 Female |
Software |
| Operating System Compatibility | Linux kernel 2.6, Windows XP, Windows 7, Windows Vista |
| Development Software | VC, VB, Delphi, BCB, LabVIEW |
Operating Conditions |
| Operating Temperature | 0...60 °C |
