Specification
System Architecture | |
| System Bus | Universal PCI |
Analog Input | |
| Total channels of analog input | 32 |
| Single-Ended channels | 32 |
| Number of Bits | 12 Bit |
| Sampling rate | 10000 Hz |
| Voltage range | +/-5 V, +/-10 V, 0...5 V, 0...10 V, +/-1.25 V, +/-625 mV, 0...2.5 V, 0…1.25 V, 0…625 mV |
Connectors | |
| Connectors | DB37 Female |
Software | |
| Operating System Compatibility | Linux kernel 2.6, Windows XP, Windows 7, Windows 8, Windows Vista |
| Development Software | VC, VB, Delphi, BCB, LabVIEW |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
