System Architecture | |
| System Bus | Universal PCI |
Analog Output | |
| Channels of analog input | 16 |
| Current range | 0...20 mA |
| Voltage range | +/-10 V |
Digital Input | |
| Total channels of digital input | 16 |
| Level of Logic "0" | 0~0.8 V |
| Level of Logic "1" | 2~5 V |
| Number of channels | 3 |
| Counter capacity | 16 Bit |
| Max frequency | 4 kHz |
Digital Output | |
| Total channels of digital output | 16 |
| Output voltage | 0~5 V |
| Max. load current | 0.8 mA |
Connectors | |
| Internal Ports | 2x20-pin box header |
| Connectors | DB37 Female |
Cables | |
| Included Cables | CA-3710 |
Software | |
| Operating System Compatibility | Linux kernel 2.6, Windows XP, Windows 7, Windows 8, Windows Vista |
| Development Software | VC, VB, Delphi, BCB, LabVIEW |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
