Construction | |
| Construction Chassis | Rubber |
| Protection Level of Front Side (Panel) | IP65 |
| Protection Level of Chassis | IP65 |
| Type | Fanless |
Display | |
| Diagonal | 7 " |
| Maximum resolution | 1024x600 Dots |
| Brightness | 850 Cd/m2 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | Intel Celeron N2930 |
| Max CPU frequency | 2.16 GHz |
Memory | |
| Form-factor | DDR3L |
| Default on Board Memory | 4 GB |
| Maximum Memory | 8 GB |
Ethernet | |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Wi-Fi | |
| Wi-Fi Standard | Yes |
Interfaces | |
| COM Total | 1 |
| RS-232 | 1 |
| USB Total | 2 |
| USB v3.x | 2 |
Drive interfaces | |
| MicroSD | 1 |
Extension Slots | |
| SIM Card slots | Micro-SIM |
Additional Functions | |
| Camera Frontside | 2 MP |
| Rear Camera | 8 MP |
| GPS | GPS |
| MSR Reader | Optional |
| NFC | Yes |
| Fingerprint Scanner | Optional |
Antenna characteristics | |
| Cellular interfaces | 4G |
| Bluetooth | v4.0 |
LED / Controls | |
| LED | 1xOn/Off LED, WWAN LED |
| Controls | Control Buttons, Function Keys |
Connectors | |
| Connectors | DB9, RJ45 Ethernet, 2xUSB, Audio (in/out/Mic), MicroSD card slot, Micro-SIM card slot |
| Docking Station | Yes |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 65 W |
| Supported Types of Power Supply | External power adapter AC/DC |
| Input Voltage AC | 100...240 V |
Battery | |
| Battery Capacity | 2900 mA*h |
Software | |
| Operating System Compatibility | Windows Embedded Standart 8.1, Windows IoT Enterprise 10, Windows Embedded 8.1 Industry |
| Operating System Installed | Windows Embedded Standard 7 |
Dimensions and weight | |
| Width | 225 mm |
| Height | 168 mm |
| Depth | 27 mm |
Operating Conditions | |
| Operating Temperature | -20...50 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
| MIL-STD-810 | MIL-STD-810G Test Method 516.4 Drop 120 cm |
