AC Power Measurement | |
| Frequency | 50/60Hz |
| Input Voltage | 10...500V AC |
| Voltage measurement channels | 2 (three-phase) |
| Input Current | 100А |
| Current measurement channels | 24 |
| Power Parameter Measurement | True RMS voltage (Vrms), True RMS current (Irms), Active Power (kW), Active Energy (kWh), Apparent Power (kVA), Apparent Energy (kVAh), Reactive Power (kVAR), Reactive Energy (kVARh), Power Factor (PF), Frequency |
Digital Output | |
| Total channels of digital output | 2 |
| Type | Electromagnitic relay |
Supported Protocols | |
| Industrial Protocols | CANopen slave |
System Power Input | |
| Input Voltage AC | 85...264 V |
Operating Conditions | |
| Operating Temperature | -20...70 °C |
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | DIN-Rail mount |
Dimensions and weight | |
| Width | 52 mm |
| Depth | 237 mm |
| Height | 134 mm |
