Specification
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | DIN-Rail mount |
Supported Protocols | |
| Industrial Protocols | Modbus TCP server |
Ethernet | |
| Total Ethernet | 2 |
| 10/100 Mbit/s | 2 |
AC Power Measurement | |
| Frequency | 50/60Hz |
| Input Voltage | 10...500V AC |
| Voltage measurement channels | 1 (three-phase) |
| Current measurement channels | 24 |
| Power Parameter Measurement | True RMS voltage (Vrms), True RMS current (Irms), Active Power (kW), Active Energy (kWh), Apparent Power (kVA), Apparent Energy (kVAh), Reactive Power (kVAR), Reactive Energy (kVARh), Power Factor (PF), Frequency, Total Harmonic Distortion (THD) |
Digital Output | |
| Total channels of digital output | 2 |
| Type | Electromagnitic relay |
System Power Input | |
| Input Voltage AC | 85...264 V |
Operating Conditions | |
| Operating Temperature | -20...70 °C |
Dimensions and weight | |
| Width | 52 mm |
| Depth | 237 mm |
| Height | 134 mm |
