Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Panel |
| Protection Level of Chassis | IP65, NEMA4 |
Display | |
| Display Type | LCD TFT |
| Diagonal | 10.4 " |
| Maximum resolution | 800x600 Dots |
CPU | |
| Processor Installed | ARM Cortex |
| Max CPU frequency | 1 GHz |
Memory | |
| Default on Board Memory | 0.5 GB |
Installed drive | |
| Flash Memory Capacity | 256 MB |
Drive interfaces | |
| SD Slots | 1 |
Software | |
| Operating System Installed | Windows CE 5.0 |
| Programming Method | IF-THEN-ELSE Logic Rules |
Ethernet | |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 3 |
| RS-485 | 3 |
| USB Total | 2 |
Supported Protocols | |
| Industrial Protocols | Modbus TCP client, Modbus RTU master |
Dimensions and weight | |
| Width | 291 mm |
| Depth | 54 mm |
| Height | 229 mm |
System Power Input | |
| Input Voltage DC | 12...48 V |
Operating Conditions | |
| Operating Temperature | -10...60 °C |
