Construction | |
| Construction Chassis | Metal Chassis with Plastic component |
| Mounting Configuration | Panel, Wall, Wall VESA 100, Wall VESA 75 |
| Protection Level of Front Side (Panel) | IP65 |
| Protection Level of Chassis | IP54 |
| Type | Fanless |
Display | |
| Display Type | LCD IPS |
| Diagonal | 21.5 " |
| Maximum resolution | 1920x1080 Dots |
| Aspect Ratio | 16:9 |
| Brightness | 250 Cd/m2 |
| Contrast Ratio | 1000~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | Intel Celeron 3955U |
| Socket | CPU onboard |
| Max CPU frequency | 2 GHz |
Chipset | |
| Chipset | Intel Skylake SoC |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Default on Board Memory | 4 GB |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Intel HD Graphics 520 |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Wi-Fi | |
| Wi-Fi Standard | 802.11ac/a/b/g/n |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 4 |
| USB 2.0 | 2 |
| USB v3.x | 2 |
Audio | |
| Audio Controller | Intel HD Audio |
Drive interfaces | |
| mSATA | 1 |
Storage Cage | |
| Number Of Cage External | 1 |
| 2.5" Cage Intenal | 1 |
Extension Slots | |
| Total | 3 |
| PCI Express x4 | 1 |
| Mini-PCIe/Mini Card | 2 |
LED / Controls | |
| LED | 1xOn/Off LED |
| Controls | KeyPad |
Connectors | |
| Connectors | 2xDB9, HDMI, 2xRJ45 Ethernet, 4xUSB, DC Input, Display Port |
System Power Input | |
| Input Voltage AC | 100...240 V |
| Power Consumption | 150 W |
Software | |
| Operating System Compatibility | Windows 7, Windows IoT Enterprise 10, Windows Embedded 8.1 Industry |
Dimensions and weight | |
| Width | 550 mm |
| Height | 360 mm |
| Depth | 65 mm |
Operating Conditions | |
| Operating Temperature | 0...40 °C |
| Shock | 20 G |
Standards and Certifications | |
| Certifications | CE, FCC Class B, EN 60601 |
| Medicine | EN 60601-1, IEC 60601-1 |
