Construction | |
| Mounting Configuration | Wall VESA 100, Wall VESA 75 |
Display | |
| Display Type | LCD TFT |
| Diagonal | 23.8 " |
| Maximum resolution | 1920x1080 Dots |
| Brightness | 250 Cd/m2 |
| Contrast Ratio | 1000~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| CPU Support Type | Core i7 |
| Max CPU frequency | 2.6 GHz |
Memory | |
| Form-factor | DDR4 |
| Default on Board Memory | 4 GB |
| Maximum Memory | 32 GB |
Graphic | |
| Graphic Controller | Intel HD Graphics 510, Intel HD Graphics 520 |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 6 |
| USB 2.0 | 4 |
| USB v3.x | 2 |
Installed drive | |
| Drive Type | SSD |
| 1st Storage Capacity | 128 GB |
Extension Slots | |
| PCI Express x4 | 1 |
| Mini-PCIe/Mini Card | 2 |
Connectors | |
| Connectors | HDMI, 2xRJ45 Ethernet, 6xUSB, Mic In, Display Port |
System Power Input | |
| Input Voltage AC | 100...240 V |
Dimensions and weight | |
| Width | 583 mm |
| Height | 386 mm |
| Depth | 69 mm |
Operating Conditions | |
| Operating Temperature | 0...40 °C |
Standards and Certifications | |
| Certifications | CE, FCC Class B |
| Medicine | EN 60601-1 |
