Construction | |
| Construction Chassis | Metal Chassis with Aluminium Heatsink |
| Mounting Configuration | Desktop, Panel, Wall, Wall VESA 100 |
| Protection Level of Front Side (Panel) | IP65 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 15 " |
| Maximum resolution | 1024x768 Dots |
| Aspect Ratio | 4:3 |
| Brightness | 400 Cd/m2 |
| Contrast Ratio | 700~1 |
Touch Screen | |
| Touch Screen Type | Resistive |
CPU | |
| Processor Installed | Vortex86DX3 |
| Max CPU frequency | 1 GHz |
Chipset | |
| Chipset | Intel ICH8M |
Memory | |
| Form-factor | DDR3 |
| Socket Type | 1xSODIMM |
| ECC | No |
| Default on Board Memory | 1 GB |
| Maximum Memory | 2 GB |
Ethernet | |
| 10/100/1000 Mbit/s | 1 |
| 10/100 Mbit/s | 1 |
Interfaces | |
| COM Total | 5 |
| RS-232/422/485 | 5 |
| USB Total | 3 |
| USB 2.0 | 3 |
Audio | |
| Audio Controller | Realtek ALC888 |
Drive interfaces | |
| CompactFlash Slots | 1 |
Storage Cage | |
| Number Of Cage External | 1 |
| 2.5" Cage Intenal | 1 |
LED / Controls | |
| Controls | On/Off, 1xReset |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | PS/2 Keyboard/Mouse, Mic In, Line In, Line Out, DC Input |
System Power Input | |
| Input Voltage DC | 12...24 V |
Power Supply | |
| Supported Types of Power Supply | External power adapter AC/DC |
Dimensions and weight | |
| Width | 409 mm |
| Height | 309 mm |
| Depth | 62.5 mm |
Operating Conditions | |
| Operating Temperature | -5...50 °C |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
| Vibration And Shock | IEC 60068-2-27 |
