Construction | |
| Construction Chassis | Stainless Steel |
| Mounting Configuration | Panel, Wall VESA 100, Wall VESA 75, Yoke mounting |
| Protection Level of Front Side (Panel) | IP66, IP69K |
| Protection Level of Chassis | IP66, IP69K |
| Type | Fanless |
Display | |
| Display Type | LCD |
| Diagonal | 17 " |
| Maximum resolution | 1280x1024 Dots |
| Aspect Ratio | 4:3 |
| Brightness | 350 Cd/m2 |
| Contrast Ratio | 800~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| СPU Generation/Family | Kaby Lake |
| Processor Installed | Intel Core i5-7200U |
| Max CPU frequency | 3.1 GHz |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Ethernet | |
| Controller Type | Intel i211-AT 10/100/1000 Mbps, Intel i219-V 10/100/1000 Mbps |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-232/422/485 | 1 |
| USB Total | 4 |
| USB 2.0 | 2 |
| USB v3.x | 2 |
Drive interfaces | |
| M.2 | 1 |
Storage Cage | |
| Number Of Cage External | 1 |
| 2.5" Cage Intenal | 1 |
Extension Slots | |
| M.2 | 1 |
| Mini-PCIe/Mini Card | 1 |
Connectors | |
| Connectors | 2xDB9, 2xRJ45 Ethernet, 4xUSB, Line Out, DC Input |
System Power Input | |
| Input Voltage DC | 9...36 V |
| Power Consumption | 15 W |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
Software | |
| Operating System Compatibility | Linux OS, Windows IoT Enterprise 10, Windows 10 |
Dimensions and weight | |
| Width | 439 mm |
| Height | 373 mm |
| Depth | 66.9 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
| Vibration | 5-500 Hz. 0.026 G²/Hz. 2.16 Grms. X. Y. Z. 1 hour per axis |
| Shock | 20 G. IEC 60068-2-27. half sine. 11 ms duration |
