Construction | |
| Mounting Configuration | Wall VESA 100, Wall VESA 75 |
| Type | Fan |
Display | |
| Diagonal | 21.5 " |
| Maximum resolution | 1920x1080 Dots |
| Brightness | 250 Cd/m2 |
CPU | |
| СPU Generation/Family | Comet Lake |
| Socket | LGA1200 |
| CPU Support Type | Celeron, Core i3, Core i5, Core i7, Pentium, Core i9 |
Chipset | |
| Chipset | Intel H410 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Maximum Memory | 32 GB |
Graphic | |
| Graphic Controller | Intel Gen9 Graphic engine |
Interfaces | |
| COM Total | 2 |
| RS-232 | 2 |
| USB Total | 6 |
| USB 2.0 | 2 |
| USB v3.x | 4 |
Extension Slots | |
| Total | 4 |
| PCI Express x16 | 1 |
| M.2 | 2 |
| Mini-PCIe/Mini Card | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 2xDB9, 6xUSB, DB15 GPIO, 3xHDMI |
System Power Input | |
| Input Voltage DC | 19...24 V |
Software | |
| Operating System Compatibility | Windows 8, Linux OS, Windows IoT Enterprise 10 |
Dimensions and weight | |
| Width | 537.8 mm |
| Height | 61 mm |
| Depth | 329.28 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
