Specification
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | DIN-Rail mount |
Industrial Interfaces | |
| Profibus DP Version | 1 |
Supported Protocols | |
| Industrial Protocols | Profibus slave |
Analog Input | |
| Total channels of analog input | 8 |
| Current range | 0...20 mA |
| Differential channels | 8 |
Connectors | |
| Connectors | DB9, Screw Terminal |
Additional Functions | |
| Watchdog timer type | Hardware, Software |
System Power Input | |
| Input Voltage DC | 10...40 V |
Dimensions and weight | |
| Width | 91 mm |
| Depth | 52 mm |
| Height | 128 mm |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
